Factory Lead Time

9 Weeks

Mount

Surface Mount

Mounting Type

Surface Mount

Package / Case

Module

Number of Pins

12

Weight

0.06oz 1.71g

Operating Frequency (Max)

100000kHz

Operating Temperature

0°C~70°C

Packaging

Tube

Published

2006

Size / Dimension

0.583Lx0.460W 14.81mmx11.68mm

Pbfree Code

yes

Part Status

Active

Moisture Sensitivity Level (MSL)

3 (168 Hours)

Termination

SMD/SMT

ECCN Code

EAR99

Applications

10/100 BASE-TX

Additional Feature

HEIGHT DIMENSION INCLUDES TERMINAL ALSO

Shielding

Unshielded

Number of Functions

1

Depth

14.73mm

Approval Agency

IEEE

Physical Dimension

L14.81XB11.68XH4.88 (mm)

Inductance

350 μH

Lead/Base Style

Gull Wing

Operating Frequency-Min

100kHz

Insertion Loss (dB)

1.2 dB

Isolation Voltage

1.5kV

Transformer Type

Isolation and Data Interface (Encapsulated)

Turns Ratio - Primary:Secondary

1:1

Return Loss

-12 dB

Height

4.88mm

Height Seated (Max)

0.202 5.13mm

Length

14.81mm

Width

11.68mm

Radiation Hardening

No

RoHS Status

RoHS Compliant

Lead Free

Lead Free
